This is my notes from the Junior Pentesting course at TryHackMe. This course takes you through the basics and some advanced topics regarding penetration testing.
NMAP Live Host Discovery
| Scan Type | Example Command |
| ARP Scan | sudo nmap -PR -sn MACHINE_IP/24 |
| ICMP Echo Scan | sudo nmap -PE -sn MACHINE_IP/24 |
| ICMP Timestamp Scan | sudo nmap -PP -sn MACHINE_IP/24 |
| ICMP Address Mask Scan | sudo nmap -PM -sn MACHINE_IP/24 |
| TCP SYN Ping Scan | sudo nmap -PS22,80,443 -sn MACHINE_IP/30 |
| TCP ACK Ping Scan | sudo nmap -PA22,80,443 -sn MACHINE_IP/30 |
| UDP Ping Scan | sudo nmap -PU53,161,162 -sn MACHINE_IP/30 |
Remember to add -sn if you are only interested in host discovery without port-scanning. Omitting -sn will let Nmap default to port-scanning the live hosts.
| Option | Purpose |
| -n | no DNS lookup |
| -R | reverse-DNS lookup for all hosts |
| -sn | host discovery only |
NMAP Basic Port Scans
- Open: indicates that a service is listening on the specified port.* Closed: indicates that no service is listening on the specified port, although the port is accessible. By accessible, we mean that it is reachable and is not blocked by a firewall or other security appliances/programs.* Filtered: means that Nmap cannot determine if the port is open or closed because the port is not accessible. This state is usually due to a firewall preventing Nmap from reaching that port. Nmap’s packets may be blocked from reaching the port; alternatively, the responses are blocked from reaching Nmap’s host.* Unfiltered: means that Nmap cannot determine if the port is open or closed, although the port is accessible. This state is encountered when using an ACK scan -sA.* Open|Filtered: This means that Nmap cannot determine whether the port is open or filtered.* Closed|Filtered: This means that Nmap cannot decide whether a port is closed or filtered.
TCP Flags
- URG: Urgent flag indicates that the urgent pointer filed is significant. The urgent pointer indicates that the incoming data is urgent, and that a TCP segment with the URG flag set is processed immediately without consideration of having to wait on previously sent TCP segments.* ACK: Acknowledgement flag indicates that the acknowledgement number is significant. It is used to acknowledge the receipt of a TCP segment.* PSH: Push flag asking TCP to pass the data to the application promptly.* RST: Reset flag is used to reset the connection. Another device, such as a firewall, might send it to tear a TCP connection. This flag is also used when data is sent to a host and there is no service on the receiving end to answer.* SYN: Synchronize flag is used to initiate a TCP 3-way handshake and synchronize sequence numbers with the other host. The sequence number should be set randomly during TCP connection establishment.* FIN: The sender has no more data to send.
Timings
| Timings | Description |
| T0 | paranoid (0) |
| T1 | sneaky (1) |
| T2 | polite (2) |
| T3 | normal (3) |
| T4 | aggressive (4) |
| T5 | insane (5) |
Summary
| Port Scan Type | Example Command |
| TCP Connect Scan | nmap -sT MACHINE_IP |
| TCP SYN Scan | sudo nmap -sS MACHINE_IP |
| UDP Scan | sudo nmap -sU MACHINE_IP |
These scan types should get you started discovering running TCP and UDP services on a target host.
| Option | Purpose |
| -p- | all ports |
| -p1-1023 | scan ports 1 to 1023 |
| -F | 100 most common ports |
| -r | scan ports in consecutive order |
| -T<0-5> | -T0 being the slowest and T5 the fastest |
| --max-rate 50 | rate <= 50 packets/sec |
| --min-rate 15 | rate >= 15 packets/sec |
| --min-parallelism 100 | at least 100 probes in parallel |
NMAP Advanced Port Scans
| Port Scan Type | Example Command |
| TCP Null Scan | sudo nmap -sN MACHINE_IP |
| TCP FIN Scan | sudo nmap -sF MACHINE_IP |
| TCP Xmas Scan | sudo nmap -sX MACHINE_IP |
| TCP Maimon Scan | sudo nmap -sM MACHINE_IP |
| TCP ACK Scan | sudo nmap -sA MACHINE_IP |
| TCP Window Scan | sudo nmap -sW MACHINE_IP |
| Custom TCP Scan | sudo nmap --scanflags URGACKPSHRSTSYNFIN MACHINE_IP |
| Spoofed Source IP | sudo nmap -S SPOOFED_IP MACHINE_IP |
| Spoofed MAC Address | --spoof-mac SPOOFED_MAC |
| Decoy Scan | nmap -D DECOY_IP,ME MACHINE_IP |
| Idle (Zombie) Scan | sudo nmap -sI ZOMBIE_IP MACHINE_IP |
| Fragment IP data into 8 bytes | -f |
| Fragment IP data into 16 bytes | -ff |
| Option | Purpose |
| --source-port PORT_NUM | specify source port number |
| --data-length NUM | append random data to reach given length |
These scan types rely on setting TCP flags in unexpected ways to prompt ports for a reply. Null, FIN, and Xmas scan provoke a response from closed ports, while Maimon, ACK, and Window scans provoke a response from open and closed ports.
| Option | Purpose |
| --reason | explains how Nmap made its conclusion |
| -v | verbose |
| -vv | very verbose |
| -d | debugging |
| -dd | more details for debugging |
NMAP Post Port Scans
| Option | Meaning |
| -sV | determine service/version info on open ports |
| -sV --version-light | try the most likely probes (2) |
| -sV --version-all | try all available probes (9) |
| -O | detect OS |
| --traceroute | run traceroute to target |
| --script=SCRIPTS | Nmap scripts to run |
| -sC or --script=default | run default scripts |
| -A | equivalent to -sV -O -sC --traceroute |
| -oN | save output in normal format |
| -oG | save output in grepable format |
| -oX | save output in XML format |
| -oA | save output in normal, XML and Grepable formats |
